Gr9 Titanium Alloy Elbow: Precision, Performance, and Reliability

Product Introduction

The Gr9 Titanium Alloy Elbow represents a cutting-edge solution for industries demanding high-performance materials. Crafted from Grade 9 Titanium, this elbow combines exceptional strength, lightweight properties, and outstanding corrosion resistance, making it a go-to choice for critical applications in aerospace, medical, chemical processing, and beyond.

Engineered to meet the most stringent industry standards, the Gr9 Titanium Alloy Elbow offers unmatched durability and adaptability, ensuring seamless integration into complex systems where reliability is paramount.

Technical Specifications

Below are the detailed specifications for the Gr9 Titanium Alloy Elbow:

Material Properties

Property	Value
Composition	Titanium (90%), Aluminum (6%), Vanadium (4%)
Density	4.48 g/cm³
Tensile Strength	620 MPa
Yield Strength	483 MPa
Elongation	15%
Hardness	30 HRC

Dimensional Standards

Standard	Specification Details
ASTM B363	Seamless and Welded Titanium Pipe Fittings
ASME SB363	Titanium and Titanium Alloy Butt-Welding Fittings
JIS H4600	Japanese Industrial Standards for Titanium

Global Production Grades

Region	Grade	Standards
USA	Grade 9	ASTM B338, AMS 4943
Russia	ВТ-22	GOST 19807-91
Japan	Ti-3Al-2.5V	JIS H4600

Product Features

Exceptional Strength-to-Weight Ratio: Lighter than steel yet stronger, ideal for high-performance systems.
Superior Corrosion Resistance: Withstands harsh chemical and marine environments.
High Durability: Designed for long-term performance under extreme conditions.
Customizable Dimensions: Tailored to meet diverse application needs.
Temperature Resilience: Performs reliably in high-temperature environments.

Applications

The Gr9 Titanium Alloy Elbow serves a wide range of industries:

Aerospace: Fuel lines, hydraulic systems, and structural components.
Medical Devices: Surgical instruments and biocompatible prosthetics.
Chemical Processing: Pipes and fittings resistant to corrosive substances.
Energy Sector: Components for nuclear, wind, and solar energy systems.
Marine Engineering: Saltwater-resistant fittings for offshore platforms.
Industrial Manufacturing: Durable parts for machinery and tooling.

Manufacturing Process

Raw Material Selection: Premium Grade 9 Titanium is sourced and inspected.
Forming: Advanced cold and hot forming processes ensure precision.
Welding and Assembly: Plasma arc welding creates seamless joints.
Heat Treatment: Enhances strength and corrosion resistance.
Surface Treatment: Polishing and anodizing for improved durability and aesthetics.
Quality Testing: Ultrasonic and eddy current testing ensure compliance with standards.

Quality Assurance

At Baoji Haiyue, quality is paramount. Every Gr9 Titanium Alloy Elbow undergoes:

Rigorous Inspections: From raw material to finished product.
Certifications: ASTM, ASME, ISO9001:2015, and AS9100D compliance.
Advanced Testing: Ultrasonic, spectral analysis, and eddy current tests guarantee consistency.

Packaging and Logistics

Secure Packaging: Anti-corrosion and impact-resistant materials safeguard products during transit.
Efficient Logistics: Global shipping options ensure timely delivery.
Custom Solutions: Packaging tailored to customer requirements.

Customer Support

Technical Consultation: Expert advice on material selection and application.
After-Sales Service: Dedicated global support team available for assistance.
Flexible Communication: Reach us via email or phone for prompt responses.

Why Choose Us

Complete Product Range: Comprehensive titanium and non-ferrous metal offerings.
Full-Process Production: In-house manufacturing ensures quality control.
Global Sales Network: Trusted by clients in over 20 countries.
Customized Solutions: Tailored products to meet specific requirements.
Fast Delivery: Efficient production and logistics for quick turnaround.
Excellent Reputation: Renowned for reliability and customer-focused service.
