grade 9 titanium sheet

1.High strength and exceptional corrosion resistance guaranteed.
2.Lightweight design, perfect for aerospace and marine industries.
3.Superior surface finish for reliable industrial applications.
4.Excellent weldability and formability for custom projects.
5.Precision thickness control ensures consistent performance.
Product Description

Grade 9 Titanium Sheet - Premium Quality, High-Performance Metal

Introduction to Grade 9 Titanium Sheet

Grade 9 titanium sheet, often known as Ti-3Al-2.5V, is a high-strength, low-alloy titanium product made from a combination of titanium, aluminum, and vanadium. This alloy is widely used in industries requiring superior performance, exceptional strength, and resistance to corrosion in harsh environments. Known for its excellent balance of mechanical properties and corrosion resistance, Grade 9 titanium sheet serves as an ideal solution in aerospace, medical, energy, and chemical industries.

Technical Specifications

Below are the technical specifications of Grade 9 Titanium Sheet, presented in three separate tables for different regions, ensuring a comprehensive understanding of this material:

United States Standards (ASTM)

Property Specification Units
Alloy Grade Ti-3Al-2.5V -
Tensile Strength 950 (min) MPa
Yield Strength 880 (min) MPa
Elongation 10-15 %
Hardness (Rockwell) 30 HRB
Density 4.43 g/cm³
Modulus of Elasticity 105 GPa
Chemical Composition Ti, 3% Al, 2.5% V -

Russian Standards (GOST)

Property Specification Units
Alloy Grade Ti-3Al-2.5V -
Tensile Strength 900 (min) MPa
Yield Strength 850 (min) MPa
Elongation 12-16 %
Hardness (Rockwell) 28 HRB
Density 4.42 g/cm³
Modulus of Elasticity 105 GPa
Chemical Composition Ti, 3% Al, 2.5% V -

Japanese Standards (JIS)

Property Specification Units
Alloy Grade Ti-3Al-2.5V -
Tensile Strength 940 (min) MPa
Yield Strength 880 (min) MPa
Elongation 12-16 %
Hardness (Rockwell) 32 HRB
Density 4.43 g/cm³
Modulus of Elasticity 105 GPa
Chemical Composition Ti, 3% Al, 2.5% V -
titanium plates titanium plates titanium plates titanium plates
titanium plates titanium plates titanium plates titanium plates

Key Features

  • High Strength-to-Weight Ratio: With excellent tensile strength and low weight, Grade 9 titanium sheets are perfect for applications that demand both high strength and minimal weight, such as aerospace and automotive industries.
  • Corrosion Resistance: Highly resistant to corrosion in a variety of environments, including saltwater and chemical exposure, making it an ideal choice for marine and chemical processing applications.
  • Biocompatibility: Suitable for medical implants and devices due to its compatibility with human tissues.
  • Versatile Applications: Grade 9 titanium is widely used for its excellent workability, weldability, and mechanical properties in various demanding applications.
  • Long-lasting Durability: Due to its superior properties, Grade 9 titanium sheet is resistant to fatigue, making it reliable for long-term use in various harsh environments.

Applications

  • Aerospace: Used for aircraft and spacecraft components that require lightweight yet strong materials.
  • Medical: Ideal for implants, surgical instruments, and prosthetics due to its biocompatibility and corrosion resistance.
  • Energy: Suitable for power plants, including nuclear reactors and wind turbine components.
  • Marine Engineering: Resists corrosion from saltwater, making it ideal for offshore platforms and marine equipment.
  • Chemical Processing: Used in the manufacturing of reactors, pipes, and storage tanks in corrosive environments.
  • Industrial Manufacturing: Essential for tools, fasteners, and machinery components requiring durability and strength.

Manufacturing Process

Grade 9 titanium sheets are produced through several advanced processes:

  1. Raw Material Preparation: Titanium, aluminum, and vanadium are melted and alloyed in precise proportions.
  2. Rolling: The alloy is rolled into sheets through hot and cold rolling techniques, ensuring the desired thickness and mechanical properties.
  3. Heat Treatment: Controlled heating enhances the material’s strength and toughness.
  4. Cutting and Shaping: Precision cutting and shaping processes are employed to meet customer specifications.
  5. Surface Treatment: To enhance corrosion resistance and aesthetic appeal, the surface is treated using advanced technologies.

Quality Assurance

Baoji Haiyue New Metal Materials Co., Ltd. ensures that every Grade 9 titanium sheet undergoes strict quality control processes:

  • Raw Material Inspection: Each batch of raw materials is tested for compliance with international standards.
  • Testing and Certification: Products are subjected to ultrasonic testing, eddy current testing, and spectral analysis to verify mechanical properties and chemical composition.
  • Final Inspection: Every product is thoroughly inspected for defects before it is dispatched, ensuring only high-quality sheets are delivered to our customers.

Packaging and Logistics

Our Grade 9 titanium sheets are securely packaged to prevent damage during transit. Packaging includes:

  • Protective coatings to avoid surface damage.
  • Custom packaging solutions available based on customer needs.
  • Fast and reliable shipping with global distribution networks.
  • We ensure that all shipments comply with international safety and transport regulations.

Customer Support

Baoji Haiyue offers exceptional customer support:

  • Pre-Sales Consultation: Expert advice to help you choose the right material for your specific application.
  • Ongoing Support: Technical assistance and product advice throughout the product life cycle.
  • After-Sales Service: Timely response to any concerns, with a global team ready to assist.

Why Choose Us

  • Comprehensive Product Range: We provide a full range of titanium products, including sheets, bars, tubes, and custom-made components.
  • One-Stop Solution: From raw material procurement to CNC machining, we offer complete services.
  • Global Reach: We have a wide network of distributors and agents worldwide.
  • Customization: Our engineering team works to deliver tailored solutions for your specific requirements.
  • Reliable Delivery: Fast delivery and dependable service, ensuring your projects stay on track.
  • Sustainability: Environmentally responsible production processes to minimize our carbon footprint.

Development History


2010


Company founded in Baoji, "Titanium Valley," specializing in titanium and non-ferrous metals.


2012

Expanded product range to include zirconium, tantalum, nickel, tungsten, and molybdenum products.


2014

Achieved ISO9001:2015 certification, ensuring high-quality production standards.


2016

Upgraded manufacturing facilities, adding VAR furnaces, CNC machinery, and advanced heat treatment systems.


2018

Expanded global presence, establishing partnerships in the United States, Germany, and South Korea.


2020

Obtained AS9100D certification for aerospace industry compliance and advanced product quality.


2022

Introduced customized solutions for the aerospace, medical, and energy industries, enhancing global reach.


2024

Celebrated 14 years of excellence with over 2,000 tons of annual titanium production capacity.



Product Quality Management

Appearance and size inspection
Appearance and size inspection
Tensile test
Tensile test
Bending test
Bending test
Chemical composition analysis
Chemical composition analysis
Electrochemical performance test
Electrochemical performance test
Ultrasonic test
Ultrasonic test
Eddy current test
Eddy current test
Thickness test
Thickness test

Production and Processing

Titanium sponge raw materials
Titanium sponge raw materials
Titanium sponge processing and smelting
Titanium sponge processing and smelting
Titanium ingot forging
Titanium ingot forging
Machining
Machining
Manual grinding and polishing
Manual grinding and polishing
Manual testing
Manual testing

Workshop and Equipment

Workshop and equipment
Workshop and equipment

Workshop and equipment

Workshop and equipment
Workshop and equipment
Workshop and equipment

Workshop and equipment

Workshop and equipment

Workshop and equipment

Workshop and equipment


Packaging

Packaging

Packaging

Packaging

Packaging

Main Products

Titanium Anode
Titanium Anode
sinrer-metal-powder-filters
Sinrer-metal-powder-filters
Titanium Rod

Titanium Rod
Titanium Plate
Titanium Plate
Titanium Elbow
Titanium Elbow
TItanium Screw
Titanium Screw

Applied Industries

Be used in a wide range of industries.



Electrolytic copper foil manufacturing industry

Electrolytic copper foil manufacturing industry

Hydrometallurgy industry

Hydrometallurgy industry

Sewage treatment industry

Sewage treatment industry

Cyclone electrolysis industry

Cyclone electrolysis industry

Etching liquid electrolysis recovery industry

Etching liquid electrolysis recovery industry

Electrolytic sodium hypochlorite industry

Electrolytic sodium hypochlorite industry

OEM Services

We offer customized solutions for Original Equipment Manufacturers (OEMs). Our dedicated team works to design and produce titanium sheets that meet your exact specifications, ensuring the perfect fit for your application.

Frequently Asked Questions (FAQs)

  • What industries use Grade 9 titanium sheets? Grade 9 titanium sheets are used in aerospace, medical, chemical processing, marine, and energy sectors.

  • Can you provide custom sizes for Grade 9 titanium sheets? Yes, we offer customized dimensions and thicknesses based on your specific needs.

  • Is Grade 9 titanium sheet biocompatible? Yes, it is highly biocompatible, making it ideal for medical implants and devices.

Contact Details

For more information or to request a quote, please contact us directly:

We look forward to helping you with your Grade 9 titanium sheet requirements!
