Gr5 Titanium Allen Bolts

1.Lightweight and strong for high-performance applications.
2.Superior corrosion resistance in extreme environments.
3.Precision threading ensures secure and reliable fastening.
4.High-temperature tolerance for demanding industrial uses.
5.Custom designs available to meet specific requirements.
Product Description

Gr5 Titanium Allen Bolts: High-Performance Fasteners for Demanding Industries

Product Introduction

Gr5 Titanium Allen Bolts are a crucial component in various high-performance applications, particularly in industries that demand strength, durability, and resistance to harsh conditions. Made from titanium alloy Gr5 (Ti-6Al-4V), these bolts combine exceptional strength-to-weight ratios with remarkable corrosion resistance, making them an ideal choice for applications across aerospace, medical, chemical, and energy industries.

Gr5 Titanium Allen Bolts are designed for use in demanding environments, offering superior performance compared to traditional steel bolts. Whether you need lightweight fasteners for aerospace or corrosion-resistant solutions for medical implants, Gr5 Titanium Allen Bolts meet the highest standards of quality and reliability.

Technical Specifications

The following table provides a detailed overview of the key specifications for Gr5 Titanium Allen Bolts, including US, Russian, and Japanese production grades and standards.

General Specifications

Specification Gr5 Titanium Allen Bolts
Material Titanium Alloy Gr5 (Ti-6Al-4V)
Tensile Strength 130,000 psi (895 MPa)
Yield Strength 120,000 psi (827 MPa)
Elongation 10-15%
Hardness 36-39 HRC
Density 4.43 g/cm³
Corrosion Resistance Excellent in marine and chemical environments
Temperature Range Up to 600°F (316°C)

Production Grades and Standards

Region Production Grade Standard
US Titanium 6Al-4V (Grade 5) ASTM B348, ASTM F136
Russia Ti-6Al-4V GOST 19807-2012
Japan Ti-6Al-4V JIS H 4652

Dimensions and Tolerances

Bolt Size Thread Size Length Range Tensile Strength Standard Thread Pitch
M5 M5 x 0.8 10-50 mm 130,000 psi 0.8 mm
M6 M6 x 1.0 15-70 mm 130,000 psi 1.0 mm
M8 M8 x 1.25 20-100 mm 130,000 psi 1.25 mm
M10 M10 x 1.5 25-120 mm 130,000 psi 1.5 mm

M14 Titanium Wheel Nut M14 Titanium Wheel Nut M14 Titanium Wheel Nut M14 Titanium Wheel Nut
M14 Titanium Wheel Nut M14 Titanium Wheel Nut M14 Titanium Wheel Nut M14 Titanium Wheel Nut

Product Features (Key Features)

  • High Strength-to-Weight Ratio: Gr5 Titanium Allen Bolts offer a remarkable balance of strength and lightness, ensuring that they perform optimally without adding unnecessary weight, which is crucial in aerospace and automotive applications.
  • Superior Corrosion Resistance: Titanium's natural corrosion resistance makes these bolts ideal for marine, chemical, and medical environments where exposure to harsh substances is common.
  • Biocompatibility: Gr5 Titanium is biocompatible, making it an excellent choice for medical applications, including surgical implants and devices.
  • Enhanced Durability: These bolts are highly resistant to wear and tear, ensuring long-term performance in high-stress environments.
  • Heat Resistance: Withstanding temperatures up to 600°F (316°C), Gr5 Titanium Allen Bolts maintain their integrity even under extreme thermal conditions.

Applications

Gr5 Titanium Allen Bolts are used in a wide range of industries where high-performance fasteners are required:

  • Aerospace: Used in aircraft and spacecraft components due to their lightweight and high-strength properties.
  • Medical Devices: Ideal for implants, surgical instruments, and other medical applications where corrosion resistance and biocompatibility are essential.
  • Chemical Processing: Gr5 Titanium Allen Bolts are highly resistant to corrosion from acids, bases, and other harsh chemicals, making them perfect for reactors, pipes, and tanks.
  • Energy Sector: Utilized in nuclear power plants, wind turbines, and solar energy applications where performance under extreme conditions is critical.
  • Marine Engineering: Their resistance to saltwater corrosion makes them ideal for offshore structures and shipbuilding.
  • Industrial Manufacturing: Often used in heavy-duty machinery, tools, and fasteners that require reliable performance under high stress.

Manufacturing Process

Gr5 Titanium Allen Bolts are manufactured using state-of-the-art processes to ensure precision, reliability, and top-tier quality:

  1. Material Selection: Only the highest-grade titanium alloy (Ti-6Al-4V) is chosen to meet the strictest industry standards.
  2. Forging: The raw titanium material is forged into bolts using advanced machinery that ensures strength and durability.
  3. Machining: Precision CNC machines are used to create the exact thread patterns and dimensions needed for each bolt.
  4. Heat Treatment: Heat treatments are applied to enhance the material's hardness and strength.
  5. Surface Treatment: Various surface treatments, such as anodizing or coating, may be applied for additional corrosion resistance.

Quality Assurance

Baoji Haiyue New Metal Materials Co., Ltd. adheres to stringent quality control measures to ensure the superior performance of Gr5 Titanium Allen Bolts:

  • Raw Material Inspection: Each batch of titanium alloy is thoroughly inspected for quality before production begins.
  • Advanced Testing: Non-destructive testing methods, including ultrasonic testing and eddy current testing, are used to identify any flaws.
  • Certification: All products are produced according to international standards such as ASTM, ISO, and AMS, ensuring they meet industry requirements.
  • Final Inspection: Each bolt undergoes a final inspection to ensure compliance with the required dimensions, strength, and surface finish.

Packaging and Logistics

Gr5 Titanium Allen Bolts are packaged carefully to ensure safe delivery to customers around the world:

  • Secure Packaging: Bolts are individually wrapped and packed in durable containers to prevent damage during transit.
  • Global Shipping: Baoji Haiyue offers worldwide shipping, with reliable logistics partners ensuring timely delivery.
  • Customs Clearance: The company handles all customs documentation to ensure smooth international shipping.

Customer Support

At Baoji Haiyue, we pride ourselves on our customer-centric approach:

  • Technical Support: Our expert engineers are available to assist with material selection and application guidance.
  • After-Sales Service: We provide comprehensive after-sales support to ensure the continued performance of our products.
  • Global Reach: No matter where you are located, our customer support team is ready to assist with your needs.

Why Choose Us?

  • Complete Product Range: Baoji Haiyue offers a full spectrum of titanium and other non-ferrous metal products, including Gr5 Titanium Allen Bolts.
  • One-Stop Solution: From raw material sourcing to final product delivery, we handle every step of the process.
  • Global Sales & Agency: We have a worldwide presence, ensuring that our products are accessible no matter where you are.
  • Custom Solutions: We specialize in providing tailored products to meet your specific needs.
  • Fast Delivery: We ensure quick turnaround times to keep your projects on schedule.
  • Reputation for Quality: With years of industry experience, we are trusted by customers across the globe.
  • Timely After-Sales Service: Our global network guarantees prompt after-sales support and door-to-door service.

Development History


2010


Company founded in Baoji, "Titanium Valley," specializing in titanium and non-ferrous metals.


2012

Expanded product range to include zirconium, tantalum, nickel, tungsten, and molybdenum products.


2014

Achieved ISO9001:2015 certification, ensuring high-quality production standards.


2016

Upgraded manufacturing facilities, adding VAR furnaces, CNC machinery, and advanced heat treatment systems.


2018

Expanded global presence, establishing partnerships in the United States, Germany, and South Korea.


2020

Obtained AS9100D certification for aerospace industry compliance and advanced product quality.


2022

Introduced customized solutions for the aerospace, medical, and energy industries, enhancing global reach.


2024

Celebrated 14 years of excellence with over 2,000 tons of annual titanium production capacity.



Product Quality Management

Appearance and size inspection
Appearance and size inspection
Tensile test
Tensile test
Bending test
Bending test
Chemical composition analysis
Chemical composition analysis
Electrochemical performance test
Electrochemical performance test
Ultrasonic test
Ultrasonic test
Eddy current test
Eddy current test
Thickness test
Thickness test

Production and Processing

Titanium sponge raw materials
Titanium sponge raw materials
Titanium sponge processing and smelting
Titanium sponge processing and smelting
Titanium ingot forging
Titanium ingot forging
Machining
Machining
Manual grinding and polishing
Manual grinding and polishing
Manual testing
Manual testing

Workshop and Equipment

Workshop and equipment
Workshop and equipment

Workshop and equipment

Workshop and equipment
Workshop and equipment
Workshop and equipment

Workshop and equipment

Workshop and equipment

Workshop and equipment

Workshop and equipment


Packaging

Packaging

Packaging

Packaging

Packaging

Main Products

Titanium Anode
Titanium Anode
sinrer-metal-powder-filters
Sinrer-metal-powder-filters
Titanium Rod

Titanium Rod
Titanium Plate
Titanium Plate
Titanium Elbow
Titanium Elbow
TItanium Screw
Titanium Screw

Applied Industries

Be used in a wide range of industries.



Electrolytic copper foil manufacturing industry

Electrolytic copper foil manufacturing industry

Hydrometallurgy industry

Hydrometallurgy industry

Sewage treatment industry

Sewage treatment industry

Cyclone electrolysis industry

Cyclone electrolysis industry

Etching liquid electrolysis recovery industry

Etching liquid electrolysis recovery industry

Electrolytic sodium hypochlorite industry

Electrolytic sodium hypochlorite industry

OEM Services

Baoji Haiyue offers OEM services, allowing customers to order customized Gr5 Titanium Allen Bolts in specific sizes, shapes, and configurations. Whether you need bulk orders or unique, small-batch products, we can accommodate your requirements.

Frequently Asked Questions (FAQs)

Q: What industries use Gr5 Titanium Allen Bolts? A: Gr5 Titanium Allen Bolts are used in aerospace, medical devices, chemical processing, energy, marine engineering, and industrial manufacturing.

Q: What are the advantages of using Gr5 Titanium for bolts? A: Gr5 Titanium offers an excellent combination of strength, light weight, corrosion resistance, and biocompatibility.

Q: Can I order customized sizes of Gr5 Titanium Allen Bolts? A: Yes, we offer customized manufacturing to meet your specific size and threading requirements.

Q: What certifications do your products have? A: Our Gr5 Titanium Allen Bolts meet ASTM, ISO, AMS, and other international standards.

Q: How can I place an order? A: You can contact us via email at jolina@bjhyti.com or call us at +86-18392721678 for a quote or more information.
